Lamdoor - Double Door

Lamdoor-small
The Lamdoor Double Door is a single swing doorset. It is hung on hinges and designed to open in one direction only.

The SDS Lamdoor system plugs the gap between a traditional laminate-faced door and the SDS DFendoor, offering a long lasting yet commercially viable alternative.

  • 2 year warranty
  • Suitable for medium and low traffic areas
  • Postformed with 1.5mm PVC
  • BM Trada Q-mark certification
  • Vision panels with timber beading
  • Available in 7 colours (including 2 wood grain options)

Lamdoor - Double Door Downloads

Lamdoor Double Door Datasheet

Download Datasheet
Lamdoor Double Door REVIT Model

Download REVIT Model
Lamdoor Double Door IFC Model

Download IFC Model

Colour options

*Disclaimer – All colours shown are web representations, and although we have given as much care and attention as possible to represent these colours visually and match them to their closest RAL colour, actual colours may vary. If a colour match is critical, please request a sample.
Snowflake LRV 81; RAL 9003
Gunpowder LRV 51; RAL 7035
Flint LRV 21; RAL 7037
Lupin LRV 23; RAL 5024
Jade LRV 36

Ratings and specifications

Fire-rating-options

Fire rating options

Select from the following fire rating options:

  • NFR, FD30/s, FD60/s
Smoke-rating


Smoke rating

Select from the following smoke rating options:

  • N/A
swing-type


Swing type

Select from the following swing type options:

  • Single or Double swing
door-thinkness

Door thickness

Select from the following door thickness options:

  • 47mm, 57mm for some acoustic ratings,
    and FD60/s fire rating
vision-pannels


Vision panels available

Select from the following available vision panels:

  • VP01, VP02, VP03, VP04, VP05, VP09, VP10, VP11, VP12, VP17, VP18,
    minimum 120mm from any leaf edge
acoustic-rating

Acoustic rating

Select from the following acoustic rating options:

  • 0-35dB
frame-type


Frame type and material

Select from the following frame type and material options:

  • Single swing, traditional or split
  • Double swing, centre
  • Hardwood or softwood
open-close


Opening min/max

Select from the following opening minimum options:

Double door - Single swing

Max Structural Opening Width
Max Structural Opening Height
1988 2149

Double door - Double swing

Max Structural Opening Width
Max Structural Opening Height
1988 2149
